MBS type Rod Mill



Brief Introduction to MBS type Rod Mill

MBS type rod mill has dry and wet two types and users can choose proper type depending on the actual needs. Our mill uses the advanced controllable feeding and discharging technologies and combines with the suitable grinding body according to the actual milling materials.

It changes the traditional surface contact into line contact. Then it has uniform output granularity and higher productivity. It is widely used in industries which have high evenness requirement such as: refractory material, chemical industry, metallurgy and glass, etc. In recent years, it is also used in building sand making industry.

Parameters of MBS type Rod Mill

Model	Shell specifications(mm)		Shell rotation speed(r/min)	Feeder granularity(mm)	Output granularity(mm)	Processing capacity(t/h)	Power(kw)	Weight(kg)
	Dia.	Length
MBS0918	900	1800	36-38	<=25	0.833-0.147	0.62-3.2	18.5	4600
MBS0924	900	2400	36	<=25	0.833-0.147	0.81-4.3	22	5100
MBS1224	1200	2400	36	<=25	0.833-0.147	1.1-4.9	30	12000
MBS1530	1500	3000	29.7	<=25	0.833-0.147	2.4-7.5	75	15600
MBS1830	1830	3000	25.4	<=25	0.833-0.147	4.8-11.6	130	28000
MBS2130	2100	3000	23.7	<=25	0.833-0.147	14-35	155	34000
MBS2136	2100	3600	23.7	<=25	0.833-0.147	19-43	180	37000
MBS2430	2400	3000	21	<=50	0.833-0.147	25-65	245	54000
MBS2736	2700	3600	20.7	<=50	0.833-0.147	32-86	380	86000
MBS2740	2700	4000	20.7	<=50	0.833-0.147	32-92	400	94000
MBS3245	3200	4500	18	<=50	0.833-0.147	64-180	630	137000
