Mineral Rod Mill



Brief Introduction to Mineral Rod Mill

Mineral rod mill is a kind of rod grinding machine. The mineral rod mill is mainly used for sand making. The mineral rod mill produced by Henan Ruiguang Mining Machinery Co., Ltd. is applied to the preparation of gold mine. Henan Ruiguang mineral rod mill has the advantages of easy operation, stable quality and high efficiency. The machine is also suitable for the preparation of other rock minerals.

Mineral Rod Mill Technical characteristics

First, crushing mainly depends on the grinding force. It is especially suitable for crushing gold. The test results are stable without rigor operation demand.

Second, the golds are crushed in the tube and they are mixed by themselves. This kind of machine does not need to be inpidually sieved.

Third, the automatic timer only contains the actual grinding time. The power failure time is not included. The machine will automatically shut down when it grinds exceeding the specified time. Since the machine is equipped with the automatic safety protection device to avoid the faults, specially-assigned persons do not need to watch the machine.

Forth, the machine is designed with a unique barrel, sweeping and dust discharge device, which significantly reduce the operator's labor intensity and silica dust hazards.

Fifth, the mineral rod mill uses the low-noise exhaust fan and the rubber rollers, which significantly reduce the noise and improve working conditions.

Parameters of Mineral Rod Mill

Model	Shell specifications(mm)		Shell rotation speed(r/min)	Feeder granularity(mm)	Output granularity(mm)	Processing capacity(t/h)	Power(kw)	Weight(kg)
	Dia.	Length
MBS0918	900	1800	36-38	<=25	0.833-0.147	0.62-3.2	18.5	4600
MBS0924	900	2400	36	<=25	0.833-0.147	0.81-4.3	22	5100
MBS1224	1200	2400	36	<=25	0.833-0.147	1.1-4.9	30	12000
MBS1530	1500	3000	29.7	<=25	0.833-0.147	2.4-7.5	75	15600
MBS1830	1830	3000	25.4	<=25	0.833-0.147	4.8-11.6	130	28000
MBS2130	2100	3000	23.7	<=25	0.833-0.147	14-35	155	34000
MBS2136	2100	3600	23.7	<=25	0.833-0.147	19-43	180	37000
MBS2430	2400	3000	21	<=50	0.833-0.147	25-65	245	54000
MBS2736	2700	3600	20.7	<=50	0.833-0.147	32-86	380	86000
MBS2740	2700	4000	20.7	<=50	0.833-0.147	32-92	400	94000
MBS3245	3200	4500	18	<=50	0.833-0.147	64-180	630	137000
