Limestone Rod Mill



Brief Introduction to Limestone Rod Mill

Henan Ruiguang Mining Machinery Co., Ltd. has always been committed to the production of mining products. Based on many years’ experience, Henan Ruiguang Mining Machinery has researched and developed new generation of rod mill products, such as limestone rod mill.

Henan Ruiguang Mining Machinery adopts advanced controllable feeding and discharging technology, combines with the actual rod grinding machines and changes the traditional surface contact into the line contact so that the particle size is more uniform and the yield is higher. Ruiguang limestone rod mill is widely used in the milling operations in refractory, chemical industry, metallurgy, glass and other industries which have relatively high requirements for the uniformity of the finished products. In recent years, the limestone rod mill is also widely used in the construction sand industry. The limestone rod mill is composed of the feeding part, cylinder, discharging part, bearing, transmission, foundation part and other components. There is a steel bar installed in the cylinder body of the limestone rod mill.


The new generation of limestone rod mill produced by Henan Ruiguang Mining Machinery has the following process characteristics. First, this kind of limestone rod mill can save power, which can save more than 40% power compared with the old type of machine. The particle size of the products is uniform. Compared with the characteristics of products of the ball mill, the characteristics curve of products of the rod mill with open circuit is almost the same as the characteristics of the products of ball mill with closed circuit. Second, the discharging granularity is uniform with high yield. Third, the discharging fineness is adjustable. The discharging fineness can be changed through simple adjustment. There is fineness control device and screening device in the machine, which can avoid overmilling phenomenon and prevent the unqualified products from mixing the finished products. The particle size characteristics of the products of rod mill are related to the situation of the crushing ores. Fourth, the limestone rod mill can be used for selective crushing with uniform particle size and little mudding role.


Ruiguang limestone rod mill is your best choice. We win customers with good faith and capture the market with excellent quality.

Parameters of Limestone Rod Mill

Model	Shell specifications(mm)		Shell rotation speed(r/min)	Feeder granularity(mm)	Output granularity(mm)	Processing capacity(t/h)	Power(kw)	Weight(kg)
	Dia.	Length
MBS0918	900	1800	36-38	<=25	0.833-0.147	0.62-3.2	18.5	4600
MBS0924	900	2400	36	<=25	0.833-0.147	0.81-4.3	22	5100
MBS1224	1200	2400	36	<=25	0.833-0.147	1.1-4.9	30	12000
MBS1530	1500	3000	29.7	<=25	0.833-0.147	2.4-7.5	75	15600
MBS1830	1830	3000	25.4	<=25	0.833-0.147	4.8-11.6	130	28000
MBS2130	2100	3000	23.7	<=25	0.833-0.147	14-35	155	34000
MBS2136	2100	3600	23.7	<=25	0.833-0.147	19-43	180	37000
MBS2430	2400	3000	21	<=50	0.833-0.147	25-65	245	54000
MBS2736	2700	3600	20.7	<=50	0.833-0.147	32-86	380	86000
MBS2740	2700	4000	20.7	<=50	0.833-0.147	32-92	400	94000
MBS3245	3200	4500	18	<=50	0.833-0.147	64-180	630	137000
