Industrial Grinding Machine



Brief Introduction to Industrial Grinding Machine

The industrial grinding machine is one of the important products produced by Henan Ruiguang Mining Machinery Co., Ltd.. This product is widely used for grinding the materials in non-ferrous metals, ferrous metals, non-metallic mineral processing, chemical industry and the building materials industry. The industrial grinding machine is the key equipment for re-crushing the materials after they have been crushed. Ruiguang new generation of ball grinding mill has changed the original structure of the mill so that the body and the chassis are integrated. They can be put on the fundamental plane together. The main bearings use the double row self-aligning roller bearings which can reduce energy consumption by 30%, improve the fine granularity and increase the processing energy by 15% to 20%. In the using process of the ball mill, we should pay particular attention to the maintenance of the ball mill.

Maintenance tips of the Industrial Grinding Machine

First, all lubricants should be let out after the mill has continuously run for one month. You should thoroughly clean the mill and replace with new oil. After that, you should change the oil every six months combining with the medium maintenance. The lubrication situation and the oil level at each lubrication point should be checked at least every four hours.

Second, in the operation of the mill, the temperature rise of the main bearing lubricating oil should not exceed 55 ℃. When the mill is in normal operation, the temperature rise of the drive bearing and the reducer should not exceed 55 ℃, and the maximum shall not exceed 60℃.

Third, the transmission of the big and small gears of the mill should be stable without abnormal noise. If necessary, you should timely adjust the gap to make the ball mill run smoothly without strong vibration. The motor current should have no unusual fluctuations.

Forth, there should be no loose phenomenon in the connection fasteners of the ball mill. If the operation of the mill is abnormal, you should timely stop the mill to overhaul it.

Parameters of Industrial Grinding Machine

Model	Shell rotation speed(r/min)	Ball load(t)	Feeding size(mm)	Discharging size(mm)	Capacity	Motor power(kw)(kw)	Weight(t)
					(t/h)
Ø900*1800	36--38	1.5	<=20	0.075-0.89	0.65-2	18.5	5.5
Ø900*3000	36	2.7	<=20	0.075-0.89	1.1-3.5	22	6.7
Ø1200*2400	36	3	<=25	0.075-0.6	1.5-4.8	30	12
Ø1200*3000	36	3.5	<=25	0.074-0.4	1.6-5	37	12.8
Ø1200*4500	32.4	5	<=25	0.074-0.4	1.6-5.8	55	13.8
Ø1500*3000	29.7	7.5	<=25	0.074-0.4	2-5	75	16.8
Ø1500*4500	27	11	<=25	0.074-0.4	3-6	110	21
Ø1500*5700	28	12	<=25	0.074-0.4	3.5-6	130	25.8
Ø1830*3000	25.4	11	<=25	0.074-0.4	4-10	130	29
Ø1830*4500	25.4	15	<=25	0.074-0.4	4.5-12	155	35.5
Ø1830*6400	24.1	21	<=25	0.074-0.4	6.5-15	210	43
Ø1830*7000	24.1	23	<=25	0.074-0.4	7.5-17	245	43.8
Ø2100*3000	23.7	15	<=25	0.074-0.4	6.5-36	155	34.8
Ø2100*4500	23.7	24	<=25	0.074-0.4	8-43	245	38
Ø2100*7000	23.7	26	<=25	0.074-0.4	8-48	280	56.6
Ø2200*4500	21.5	27	<=25	0.074-0.4	9-45	280	51.8
Ø2200*6500	21.7	35	<=25	0.074-0.4	14-26	380	60
Ø2200*7000	21.7	35	<=25	0.074-0.4	15-28	380	62
Ø2200*7500	21.7	35	<=25	0.074-0.4	15-30	380	64.8
Ø2400*3000	21	23	<=25	0.074-0.4	7-50	245	54
Ø2400*4500	21	30	<=25	0.074-0.4	8.5-60	320	65
Ø2700*4000	20.7	40	<=25	0.074-0.4	12-80	380	94
Ø2700*4500	20.7	48	<=25	0.074-0.4	12-90	480	102
Ø3200*4500	18	65	<=25	0.074-0.4	-----	800	137
Ø3600*4500	17	90	<=25	0.074-0.4	-----	850	158
Ø3600*6000	17	110	<=25	0.074-0.4	-----	1250	175
