Flotation Machine

Technical Process of Flotation Machine

This flotation machine is suitable for separating non-ferrous and ferrous metals as well as non metals such as fluorite and talc.This machine runs by the triangle belt of the electrical motor driving the impellor to rotate, producing centrifugal effect which will form negative pressure, and on one hand it will absorb sufficient air in order to mix with the pulp, and on the other hand it will mix the pulp in order to mix with the reagents, and at the same time will refine the foam in order to stick the minerals onto the foam, and float on the surface of the pulp in order to become mineralization foam. The workers can adjust the height of the flashboard and control the liquid level in order to scrap the useful foam.

Instruction for Use

Before starting the machine, first check the bolts of all spare parts and before stopping the machine, manually spin the wheel to prevent the depositing of sediment from increasing the load of electro motor. During the working process, carefully adjust the height of the flashboard to maintain the stability of the liquid level, so that the mineralized bubbles on the liquid surface of the pump can be timely scraped to the launder. A certain space should be maintained between the impeller and the stator, and when the impeller is abraded, it should be changed timely, and the bearing inside the pump should be maintained every three month.

Technical Parameters of SF Flotation Machine

Model		SF0.37	SF0.7	SF1.2	SF2.8	SF4	SF8
Trough capacity(m3)		0.37	0.7	1.2	2.8	4	8
Blade diameter(mm)		300	350	450	550	650	T60
Production capacity(m3/min)		0.2-0.4	0.3-0.9	0.6-1.2	1.5-3.5	0.5-4	4-8
Blade rotation speed(m3/min)		352	400	312	268	238	191
Motor	Model	①Y90L-4	①Y100L2-4	①Y132M2-6	①Y160L-6	①Y180L-6	①Y250M-8
		②Y90S-4	②Y90S-4	②Y90S-4	②Y90S-4	②Y90L-4	②Y100L-6
	Power(kw)	①1.5	①3	①5.5	①11	①15	①30
		②1.1	②1.1	②1.1	②1.1	②1.5	②1.5
Dimensions(mm)		700*700*750	900*820*950	1100*1100*1100	1700*1600*1150	1850*2050*1200	2200*2900*1400
Single trough weight(kg)		468	600	1373	2338	2660	4486

Technical Parameters of BF Flotation Machine

Model	Trough cubage(m3)	Internal dimensions(L×W×H)(m)	Air suction amount(m3/m2.min)	Power(kw)	Motor moder	Processing capacity(m3/min)	Single trough weight(kg)
BF-0.37	0.37	0.74×0.74×0.75	0.9~1.05	1.5	Y90L-4	0.2-0.4	470
BF-0.65	0.65	0.85×0.95×0.9	0.9~1.10	3.0	Y132S-6	0.3-0.7	932
BF-1.2	1.2	1.05×1.15×1.10	1.0~1.10	5.5 4.0	Y132M2-6 Y132M1-6	0.6-1.2	1370
BF-2.0	2.0	1.40×1.45×1.12	1.0~1.10	7.5	Y160M-6	1.0-2.0	1750
BF-2.8	2.8	1.65×1.65×1.15	0.9~1.10	11	Y180L-8	1.4-3.0	2130
BF-4.0	4.0	1.9×3.0×1.2	0.9~1.10	15	Y200L-8	2-4	2585
BF-6.0	6.0	2.2×2.35×1.3	0.9~1.10	18.5	Y225S-8	3-6	3300
BF-8.0	8.0	2.25×2.85×1.4	0.9~1.10	22 30	Y225M-8 Y250M-8	4-8	4130
BF-10	10	2.25×2.85×1.7	0.9~1.10	22 30	Y225M-8 Y250M-8	5-10	4660
BF-16	16	2.85×3.8×1.7	0.9~1.10	37 45	Y280S-8 Y280M-8	8-16	8320
BF-20	20	2.85×3.8×2.0	0.9~1.10	37 45	Y280S-8 Y280M-8	10-20	8670
BF-24	24	3.15×4.15×2.0	0.9~1.10	45	Y280M-8	12-24	8970
